LiftMaster Opener Error Code 2-3: Meaning and Fix

2-3
How 2-3 appears on a LiftMaster opener display.
LiftMaster opener code 2-3: logic board
Chamberlain Group product image, liftmaster.com

Also shown as: 23, Up 2 Down 3

Reading the opener display

A garage door opener reports faults through blinking LEDs on the motor head, a diagnostic window on the logic board, or the wall control. Count the flashes slowly and repeat the count before you decide what you saw. On LiftMaster the Learn button color and the count of flashes together identify the board.

LiftMaster, from the Chamberlain Group, is the professional-installer line. Its openers with a yellow Learn button report faults as LED flash counts or two-digit diagnostic codes such as 1-1 or 4-5 on the logic board. The codes apply to model numbers such as 8500W and 87504-267; check the label on your unit to confirm yours.

What causes 2-3

How to fix it

  1. Unplug the opener for a full 60 seconds, then plug it back in and try a cycle; some board faults are transient.
  2. Remove the light lens and head cover and look for burn marks, corrosion, bugs or loose connectors.
  3. Check that the wall control, sensors and travel module cables are firmly seated; a bad accessory can mimic a board fault.
  4. If the code returns, note the model number and order the matching logic board.
  5. Swap the board, relearn remotes and keypads, and run the limit and force setup.

Parts you may need

PartPart no.Buy
Receiver logic board, AC041AC050-2MFind part
Transformer and wire harness041A7635Find part

Part numbers are OEM references; confirm fit by your model number before ordering. Some links are affiliate links; we may earn a commission at no extra cost to you.

Questions

What does code 2-3 mean on a LiftMaster opener?

It signals a logic board fault. Reports list 2-1 through 2-5 as board problems.

Is 2-3 fixable without replacing the board?

Sometimes a power cycle helps, but a repeat usually means replacement.

Will I lose my remotes?

After a board swap you must relearn remotes and keypads.

Other LiftMaster opener codes

LiftMaster opener code Yellow Learn LED rapid flash: openerYellow Learn LED rapid flashStuck button on a remote or keypadLiftMaster opener code 1-1: safety sensor pair1-1Safety sensor wire open or sensors not connectedLiftMaster opener code 1-2: safety sensor1-2Safety sensor wire shorted or reversedLiftMaster opener code 1-3: wall control panel1-3Door control wire shortedLiftMaster opener code 1-4: safety sensor with sunblocker1-4Safety sensors misaligned or beam blockedLiftMaster opener code 1-5: travel module1-5Travel module or RPM sensor fault

Sources

Part numbers are OEM references; confirm fit by your model number before ordering. Meanings compiled from manufacturer and parts-retailer documentation; see sources below. Unplug the appliance before opening it.

Applies to models including 8500W, 87504-267, LJ8900W, 2265, 2280, 1240R, 1345, 8075.
